4-6 Input / Output MN1957
www.baldormotion.com
Figure 7: Analog output - typical connection to Baldor FlexDrive
II
, Flex+Drive
II
, MintDrive
II
X13 X1
Drive
amplifier
±10 VDC
demand
input
11
22
3
NextMove ESB-2 FlexDrive / drive amplifier
II
Connect overall shield
at one end only
AIN0+
AIN0-
Shield
AGND
Demand0
-
+
