Baldor NextMove ESB-2 User Manual

MN1957 Input / Output 4-17
www.baldormotion.com
Figure 21: Encoder input 0 - typical connection from a drive amplifier
(e.g. Baldor FlexDrive
II
, Flex+Drive
II
or MintDrive
II
)
MicroFlex
FlexDrive
encoder output
II
Flex+Drive
MintDrive
II
II
NextMove ESB-2
CHA+
CHB+
CHZ+
CHA+
CHB+
CHZ+
CHA-
CHB-
CHZ-
DGND
CHA-
CHB-
CHZ-
DGND
Shield
X7 X5
6
7
8
6
7
8
55
4
1
2
3
1
2
3
to CPU
to CPU
to CPU
Vcc
Vcc
Vcc
10k
10k
10k
120R
120R
120R
MAX3095
MAX3095
MAX3095
Connect overall shield to
connector backshells /
shield connections.
Twisted pair
Twisted pair
Twisted pair
