1.1 Validity
This guide provides all necessary information for the safe
use of the following EtherNet/IP IO-Link master:
– BNI-EIP-508-105-Z015
Order code: BNI006A
With display
– BNI-EIP-508-005-Z015-013
Order code: BNI00HM
Without display
Read this guide and the other applicable documents
completely before installing and operating the product.
Original User’s guide
This guide was created in German. Other language
versions are translations of this guide.
© Copyright 2023, Balluff GmbH
All contents are protected by copyright. All rights reserved,
including the rights of reproduction, distribution,
processing and translation.
1.2 Other applicable documents
Additional information about this product can be found at
www.balluff.com on the product page, e.g.in the
following documents:
– Data sheet
– Declaration of Conformity
– Disposal
1.3 Symbols and conventions
Individual instructions are indicated by a preceding
triangle.
► Instruction
Action sequences are numbered consecutively:
1. Instruction 1
2. Instruction 2
Numbers unless otherwise indicated are decimals
(e.g.23). Hexadecimal numbers are represented with a
preceding 0x (e.g.0x12AB).
Buttons or selectable menu entries are described in italic
and small caps, e.g.
Save.
Menu commands are joined with a greater-than sign,
e.g.“
SettingS > OptiOnS” stands for the menu command
Options from the Settings menu.
Note, tip
This symbol indicates general notes.
1.4 Explanation of the warnings
Always observe the warnings in this guide and the
measures described to avoid hazards.
The warnings used here contain various signal words and
are structured as follows:
SIGNAL WORD
Type and source of the hazard
Consequences if not complied with
► Measures to avoid hazards
The individual signal words mean:
NOTICE
Identifies a danger that could damage or destroy the
product.
CAUTION
The general warning symbol together with the signal
word CAUTION indicates a hazard which can lead to
slight or moderate injuries.
DANGER
The general warning symbol in conjunction with the
signal word DANGER identifies a hazard which, if not
avoided, will certainly result in death or serious injury.
1.5 Technical terms and abbreviations used
C/Q Switching and communication line
EIP EtherNet/IP
EMC Electromagnetic compatibility
FE Functional earth
GND Electrical ground, 0V
I/O Standard inputs and outputs
IOL IO-Link
ISDU IO-Link-Parameter (Index Service Data Unit)
n.a. Not available
UA Actuator supply
US Sensor supply
1.6 Pictures
Product views and pictures in these operating instructions
may differ from the specified product.
