www.balluff.com 13english
The specifications are typical values for 24VDC at room
temperature.
The product is immediately ready for use.
For performance data for UL, see chapter8.7.2 on
page14.
Further data can be found at www.balluff.com
on the product page.
8.1 Ambient conditions
Ambient temperature −5…+70°C
Storage temperature −25…+70°C
Protection class
(inscrewed state)
IP67
8.2 Electrical data
Operating voltage Ub 18…30.2VDC, as
perEN 61131-2
Residual ripple <1%
Input current at 24V 130mA
8.3 Electrical connection
Connection (power supply IN/
OUT)
7/8", 4-pin, plug/socket
Input/output ports M12, A-coded,
8×socket
8.4 Interface
EtherNet/IP
EtherNet/IP Port 2×10Base/100Base-Tx
Connection for EtherNet/IP Port M12, D-coded, socket
Cable types as per IEEE 802.3 Shielded twisted pair
min. STP CAT5/ STP
CAT5e
Data transmission rate 10/100Mbit/s
Max. cable length 100m
Flow control Half-duplex/full-duplex
(IEEE 802.33x-Pause)
IO-Link
IO-Link version 1.1.3
Transmission rate
COM1 4.8kBaud
COM2 38.4kBaud
COM3 230.4kBaud
Port class PortClassA (8×)
8.5 Materials
Housing material Zinc die-cast
8.6 Mechanical features
Installation 2-hole screw mounting
Ground strap fastening Screw M4
Dimensions (W×H×D) 68×224×37.9mm
Weight Approx. 670g
8
Technical data
BNI EIP-508- _ 05-Z015- _ _ _
Network interface
