Balluff BNI EIP-508 05-Z015 Series User Manual

www.balluff.com 7english
4
Product description
Fig.4-1: Dimensions, design and function
4.1 Construction
Fig.4-2:
EtherNet/IP Port 2EtherNet/IP Port 1
Power supply inputPower supply output
Port 4Port 0
Port 5
Port 1
Port 6
Port 2
Port 7
Port 3
Mounting hole
Mounting hole
FE connection
Device overview
4.2 Function
The Ethernet/IP-IO-Link master is a decentralized and
configurable gateway that processes and evaluates the
input and output signals of standard sensors and actuators
as well as process data from connected IO-Link devices.
The data is transmitted via an existing fieldbus interface to
a higher-level controller set up by the user for further
processing.
A web server is available on the IO-Link master for
configuration and diagnostics.
For configuration information, see the
configuration guide at www.balluff.com on the
product page.
BNI EIP-508- _ 05-Z015- _ _ _
Network interface
