Technical data (continued)
8.7 Approvals and markings
Additional information on directives, approvals and
standards can be found at www.balluff.com on
the product page.
The product meets the requirement of the EN 61131-2
standard for zone A.
8.7.1 CE
The CE Mark verifies that our products
meet the requirements of the current EU
Directive.
8.7.2 UL
Cleaning
Clean the product only with dry cloth or cloth dampened
only with water!
UL requirements
File E319845
Classification Type 1
Ambient tempe-
rature
+45°C
The power supply has to be an isolated type or SELV type.
Performance data
Power input, nominal
rated voltage 24VDC
– 130mA maximum
consumption
– 9A including all output loads
Power output, nominal
rated voltage 24VDC
– max. 8.8A
Digital input, nominal
rated voltage 24VDC
– max. 30mA/pin (point)
Digital output, nominal
rated voltage 24VDC
Class A IO-Link Port pin1/3
– 0.5A/Port Pilot Duty
– 1.6A/port (point) Resistive /
General use
Class A IO-Link Port pin2/3
– 0.5A/Port Pilot Duty
– 2A/port (point) resistive/
general use (switchable)
Class A IO-Link Port pin4/3
– 0.5A/Port Pilot Duty
– 2A/port (point) resistive/
general use (switchable) +
IO-Link
– 8.8A or less per device
Cable sizes
Power supply cable:
Listed or R/C cable (CYJV2) with 7/8" 4-pin threaded
connector with minimum 24V, minimum 9A for all models.
S, SJ, SO, ST, SV or R/C (AVLV2) cables identified or
specified on the UL Style Page as suitable for external
connections, rated 300V or greater, 14AWG or larger,
unless identified with the maximum load current and
overcurrent protection for the cable in accordance with the
table below.
Mains connection cable:
Listed or R/C cable (CYJV2) with a 7/8", 4-pin female
threaded connector and a rated voltage of at least 24V
and at least 9A for all models. Listed S, SJ, SO, ST, SV or
R/C cable (AVLV2) marked or specified on the UL Style
Page as suitable for external connections, rated 300V
minimum and 14AWG minimum, unless marked with the
maximum load current and overcurrent protection for the
cable in accordance with the table below.
Communication cable:
Listed or R/C cable (CYJV2) with A, B, or D-coded male or
female threads, as applicable, for connection to Article9,
M12 plug rated 24V minimum and 1A minimum. R/C
cable (AVLV2), identified or specified on the UL Style Page
as suitable for external connections, with minimum
28AWG and minimum 300V.
Input/output cable:
Listed or R/C cable (CYJV2) with A-coded M12 threaded
connector, minimum 24V, minimum 4A. R/C cable
(AVLV2), identified or specified on the UL Style Page as
suitable for external connections, rated 300V or greater,
20AWG or larger, unless the maximum load current and
overcurrent protection for the cable are specified in
accordance with the table below.
Cable conductor
size, AWG
14 16 18 20 22 24 26 28 30
Overcurrent
protection
maximum
amperage [amps]
12 8 5.6 5 3 2 1 0.8 0.5
Maximum load
[amps]
9 8 5.6 4 2.4 1.6 0.8 0.6 0.4
Tab. 8-1: Cable sizes
