ALPHA 2 Pro™ Wave Operator’s Instruction Manual
MKT-AH-1CC40ST [A] 15
STEP 4. To close the security panel, route any cables where
they will not be pinched, and insert the security panel
up into the cabinet from under the button deck area
until the door connects to the cabinet frame securely.
Installing the Upper Door
STEP 1. Close the upper door latch by pressing it towards the
back of the cabinet.
CAUTION
To ensure wires and cables are not pinched,
abraded, or otherwise damaged, use care when
inserting and removing doors.
CAUTION
The door is large and heavy. To prevent injury or
damage, enlist the aid of another technician
during installation.
MKT-AH-1CC40ST.book Page 15 Friday, November 15, 2013 3:47 PM
