ALPHA 2 Pro™ Wave Operator’s Instruction Manual
38 MKT-AH-1CC40ST [A]
Cabinet Signal Cable (236492-00-0)
This cable includes wiring for some systems connections. If your
system requires a customized cable, then disconnect the systems
connectors on this cable.
Cabinet Signal Cable - Systems Interconnect Pin-Outs
Pin Color Description
1Yellow/GreyGround
2 Yellow/White Monitor/Middle Door Switch
3 Gray/Green-2 Ground
4 Red/White-1 Cash Box Door (NO) WT/RD
5 Grey/Green-3 Ground
6 Blue/White-1 Cash Box Present (NO)
7Green-1 Transmit
8 Orange/Grey Ground
9White/Green-2Receive
10 Orange/White Belly (Middle) Door Switch
11 Green/Grey Ground
12 Violet 5V Sense
13 White/Blue-1 Logic Door (NO)
14 Blue Logic Door (NC)
15 Grey/Blue-1 Logic Door Common
