ALPHA 2 Pro™ Wave Operator’s Instruction Manual
MKT-AH-1CC40ST [A] 3
Electrical Specifications
NOTE
Typical currents are provided for reference only. Actual current use
will depend upon machine configuration and addition of
supplemental equipment such as, but not limited to, the following:
systems monitoring equipment, progressive equipment, and
service equipment.
Description Wave Cabinet
Line Voltage 120 VAC at 60 Hz
(230 VAC at 50 Hz)
Surge State Current 1.4 Amps at 120 VAC (0.70 Amps at 240 VAC)
Operating State Current 1.97 Amps at 120 VAC (0.985 Amps at 240 VAC)
Fuse Limited Rated
Current
6.3 Amps at 120 VAC (3.15 Amps at 230 VAC)
Heat Generated (BTU/HR) 766
MKT-AH-1CC40ST.book Page 3 Friday, November 15, 2013 3:47 PM
