Bally ALPHA 2 Pro Wave - Components for Lighting Control Unit (LCU) Board (PCA235737-0-0); LCU Board DIP Switch Settings

ALPHA 2 Pro™ Wave Operator’s Instruction Manual
34 MKT-AH-1CC40ST [A]
LCU Board DIP Switch Settings
Components for Lighting Control Unit (LCU) Board (PCA235737-0-0)
Component Typical Usage and Description
J2 Indicator light
Power Power cable connector
Port 0 Super candle tower light or 42-Inch Facade, 16-pin
connector
Port 1 Super candle tower light or 42-Inch Facade, 16-pin
connector
Port 2 Cabinet side lights or Pro Topper (Marquee with
FPD monitor), if installed, 12-pin micro connector
Port 3 Cabinet side lights or Pro Topper (Marquee with
FPD monitor), if installed, 12-pin micro connector
Port 4 Cabinet side lights or Pro Topper (Marquee with
FPD monitor), if installed, 12-pin micro connector
Port 5 Coin tray light or other simple device
Port 6 Coin tray light or other simple device
Port 7 Bally logo light, red
SW1 DIP Switch for manually setting light colors
USB LCU to MPU communication cable connector
Color Red Green Blue Reserved
DIP Switch12345678
0% off off off off off off off off
33% on off on off on off off off
66% off on off on off on off off
100% on on on on on on off off
