ALPHA 2 Pro™ Wave Operator’s Instruction Manual
30 MKT-AH-1CC40ST [A]
J12 RCU POWER RCU Power Connector
J13 DC POWER BULKHEAD DC Power for the Bulkhead
J14 MPU BACKPLANE MPU Backplane Connector
J15 7-SEG DISP METER, POWER
AND PAYLINE
7-Segment Display Meter Power
and Payline Power
J16 COIN MECH AND HOPPER
Coin Acceptor and Hopper
Connector
J17 SPARE D/C POWER Spare DC Power
J18 SPARE D/C POWER Spare DC Power
L1 INPUT POWER FILTER Power Connector
Connectors for Power Backplane Board (PCA212319-0-0)
Connector Usage
