ALPHA 2 Pro™ Wave Operator’s Instruction Manual
32 MKT-AH-1CC40ST [A]
Connectors for Signal Backplane Board, ALPHA 2 (PCA235204-0-0)
Connector Usage
BH1
Battery for memory retention when
the power is off
J1 SERVICE LIGHT Service Light Connector
J3 SYSTEMS Systems Connector
J4 POWER INTERFACE Power Backplane Connector
J5 ATTEND. SWITCHES Attendant Switch
J6 COUNTERS
Electro-mechanical Counter
Connector
J7 TOWER Tower Light Connector
J9 COM5 —
J11 COM9 (For future use.)
J12 COM8
GAT communication port
connector
J13 COM7
Host 2 (secondary SAS) systems
cable connector or printer
J14 COM1
Host 1 (primary SAS) systems cable
connector
J15 TOP BOX COM 6 Top Box Connector
J16 COIN/HOPPER I/O
Coin Acceptor and Hopper
Connector
J17 DECK BUTTONS Button Signal Connector
J18 BILL ACCEPTOR COM2
CARD READER COM4
PRINTER COM3
Bill Acceptor Connector and Printer
or Card Reader Connector
P1 MPU Board connector
P2 MPU Board connector
U1 DOOR SWITCH INPUTS All Door Input Switch Connector
