Technical data
8LS...-3 user's manual V2.50 215
Model number 8LSC76.ee015ffgg-3 8LSC76.ee030ffgg-3 8LSC77.ee030ffgg-3 8LSC78.ee030ffgg-3
Motor
Nominal speed n
N
[rpm] 1500 3000
Number of pole pairs 5
Nominal torque M
n
[Nm] 66 47.3 53.6 59
Nominal power P
N
[W] 10367 14860 16839 18535
Nominal current I
N
[A] 20.25 29 32.9 36.2
Stall torque M
0
[Nm] 75 91.2 104
Stall current I
0
[A] 23.01 46 56 63.8
Maximum torque M
max
[Nm] 230 270 330
Maximum current I
max
[A] 92.5 185 212 260
Maximum speed n
max
[rpm] 4500
Torque constant K
T
[Nm/A] 3.26 1.63
Voltage constant K
E
[V/1000 rpm] 196.87 98.44
Stator resistance R
2ph
[Ω] 0.57 0.15 0.11 0.08
Stator inductance L
2ph
[mH] 11.5 2.7 2.2 1.8
Electrical time constant t
el
[ms] 17.85 18 18.2 22.5
Thermal time constant t
therm
[min] 56 65 74
Moment of inertia J [kgcm
2
] 102 130 158
Weight without brake m [kg] 36 44 52
Holding brake
Holding torque of brake M
Br
[Nm] 47
Mass of brake [kg] 0
Moment of inertia of brake J
Br
[kgcm
2
] 32
Recommendations
ACOPOS 8Vxxxx.xx... 1320 1640 128M
ACOPOSmulti 8BVIxxxx... 0330 0660 0880
ACOPOS P3 8EIxxxx... 034X -
Cross section for B&R motor cables
[mm
2
]
4 10 16
Connector size 1.5 1.5/16
NOTE about servo drives: The recommended servo drive / inverter module is designed for 1.1x the stall current. If more than double the amount is needed during
the acceleration phase, the next larger servo drive should be selected. This recommendation is only a guideline; detailed inspection of the corresponding speed/
torque characteristic curve can result in deviations of the servo drive size (larger or smaller).
NOTE about cable cross section: The B&R motor cables with this cable cross section are produced optimally (cables stripped to the correct length) for the
ACOPOS servo drive or the recommended ACOPOS inverter module. B&R motor cables with other cable cross sections can also be used (within the specified
terminal cross section range) and can be obtained from B&R in the desired design on request. Note the type of wiring.
