Banner D10 Series - Page 32

Included Bracket Dimensions
10.0 mm
(0.39")
35.1 mm
(1.38")
10.0 mm
(0.39")
15.2 mm
(0.60")
2x C’sink
ø8.0 mm (0.31")
3.2 mm (0.13") deep
ø4.4 mm (0.18") thru
2x 3.5 mm
(0.14")
5.0 mm
(0.20")
8.6 mm
(0.34")
25.4 mm
(1.00")
16.0 mm
(0.63")
2 x ø3.3 mm (0.13")
2x ø3.2 mm (0.13")
2.5 mm (0.10")
5.0 mm (0.20")
M3 Hardware included:
Lock Washer (2)
Flat Washer (2)
Screws (2)
Hex Nuts (2)
Fiber Optic Array Dimensions
14.5 mm
[0.57”]
83 mm
[3.27”]
42 mm
[1.65”]
30 mm
[1.18”]
10 mm
[0.39”]
75 mm
[2.95”]
25 mm
[0.98”]
4x 3.2 mm dia [0.13”]
Figure 3. PFCVA-10X25-S and PFCVA-10X25-E
D10 Expert Series - Small Object Counter
