Banner D10 Series User Manual

14.5 mm
[0.57”]
83 mm
[3.27”]
30 mm
[1.18”]
42 mm
[1.65”]
25 mm
[0.98”]
75 mm
[2.95”]
25 mm
[0.98”]
4x 3.2 mm dia [0.1260”]
Figure 4. PFCVA-25X25-S and PFCVA-25X25-E
14.5 mm
[0.57”]
83 mm
[3.27”]
25 mm
[0.98”]
30 mm
[1.18”]
42 mm
[1.65”]
4x 3.2mm dia [0.1260”]
75 mm
[2.95”]
34 mm
[1.34”]
Figure 5. PFCVA-34X25-S and PFCVA-34X25-E
D10 Expert Series - Small Object Counter
P/N 146132 Rev. D www.bannerengineering.com - Tel: +1-763-544-3164 11
