Specifications
Required Fiber-Optic Cable
Banner P-Series plastic fibers
Sensing Beam
680 nm visible red or 525 nm visible green, depending on model
Supply Voltage and Current
4-20 mA Analog Models: 12 to 24 V dc (10% maximum ripple) at less than 65
mA, exclusive of load
0-10 V dc Analog Models: 15 to 24 V dc (10% maximum ripple) at less than 70
mA, exclusive of load
Supply Protection Circuitry
Protected against reverse polarity and transient voltage
Output Configuration
Two independently configurable outputs, depending on model: NPN w/analog
(4-20 mA or 0-10 V) or PNP w/analog (4-20 mA or 0-10 V)
Output Rating
Discrete Output: 150 mA, maximum load
OFF-state leakage current: < 10 μA at 24 V dc
ON-state saturation voltage: NPN: < 1.5 V at 150 mA load; PNP < 2.5 V at 150
mA load
Analog Output: 4-20 mA or 0-10 V dc
Load: 4-20 mA Models: 100Ω maximum impedance; 0-10 V dc Models: 1 MΩ
min. impedance
Adjustments
Push-button or remote programming of response time, OFF-delay, light/dark
operate, and display
Indicators
Four-digit digital display plus LED indicators for active channel, push-button
lockout, OFF-delay and light/dark operate selection; 2 yellow output indicators
Construction
Black ABS/polycarbonate alloy (UL94 V-0 rated) housing, clear polycarbonate
cover
Connections
PVC-jacketed 2 m or 9 m (6.5 ft or 30 ft) 6-wire integral cable or integral 6-pin
Pico-style quick-disconnect
Installation
35 mm DIN rail or included mounting bracket
Output Response Time
Discrete Output: Programmable, 50 microseconds, 200 microseconds, 1
millisecond, 2.5 milliseconds
Analog Output: 1 millisecond
NOTE: < 1 second delay on power-up; outputs do
not conduct during this time.
Output Protection Circuitry
Protected against false pulse on power-up and continuous short-circuit
Operating Conditions
Temperature: –20 to +55 °C (–4 to +131 °F)
Storage: –20 to +80 °C (–4 to +175 °F)
Max. Rel. Humidity: 90% at 50 °C (non-condensing)
Number of Devices, Stacked Ambient Temperature Rating Load Specification
3 55 °C (131 °F) 150 mA
7 50 °C (122 °F) 50 mA
10 45 °C (113 °F) 50 mA
Environmental Rating
IEC IP50, NEMA 1
Certifications
Required Overcurrent Protection
WARNING: Electrical connections must be made
by qualified personnel in accordance with local and
national electrical codes and regulations.
Overcurrent protection is required to be provided by end product application per
the supplied table.
Overcurrent protection may be provided with external fusing or via Current
Limiting, Class 2 Power Supply.
Supply wiring leads < 24 AWG shall not be spliced.
For additional product support, go to http://www.bannerengineering.com.
Supply Wiring (AWG)
Required Overcurrent Protection (Amps)
20 5.0
22 3.0
24 2.0
26 1.0
28 0.8
30 0.5
D10 Expert
™
- Analog and Discrete Outputs
14 www.bannerengineering.com - Tel: +1-763-544-3164 P/N 65448 Rev. G
