Method Acon Result
SET Buon Move Mode switch to RUN Display: Red - Signal Level; Green -
Threshold
Remote Input No acon required; sensor returns to RUN
mode automacally
3.6 Troubleshoong
3.6.1 Manual Adjustments Disabled
Manual adjustments are disabled when Auto Thresholds are ON. If a manual adjustment is aempted while Auto Thresholds are ON,
the Green display will ash .
3.6.2 Percent Minimum Dierence
aer TEACH
The Two-Point and Dynamic TEACH methods will ash a % minimum dierence on the displays aer a PASS or FAIL.
Value PASS/FAIL Descripon
0 to 99% FAIL The dierence of the taught condions does not meet the required minimum
100 to 300% PASS The dierence of the taught condions just meets/exceeds the required minimum, minor
sensing variables may aect sensing reliability
300 to 600% PASS The dierence of the taught condions suciently exceeds the required minimum, minor
sensing variables will not aect sensing reliability
600% + PASS The dierence of the taught condions greatly exceeds the required minimum, very stable
operaon
3.6.3 Percent Oset aer SET
The Window, Dark, and Light SET methods will ash a % oset on the displays aer a PASS or FAIL.
SET Result %
Oset Meaning
PASS (with % Oset) Displays the % oset used for the SET method
FAIL (with % Oset) Displays the minimum required % oset necessary to PASS the SET method
FAIL (without % Oset) Presented condion cannot be used for the SET method
3.6.4 Threshold Alert or Threshold Error
Severe contaminaon/changes in the taught condion can prevent the Auto Thresholds algorithm from opmizing the threshold(s).
State Display Descripon Correcve
Acon
Threshold Alert Alternates
and
The threshold(s) cannot be opmized,
but the sensor's output will sll
connue to funcon
Cleaning/correcng the sensing
environment and/or a re-teach of the sensor
is highly recommended
Threshold Error The threshold(s) cannot be opmized,
and the sensor's output will stop
funconing
Cleaning/correcng the sensing
environment and/or a re-teach of the sensor
is required
DF-G3 Long Range Expert
™
Dual Display Fiber Amplier
www.bannerengineering.com - Tel: 763.544.3164 25
