Page 12
For Beefmaster Deluxe Four Burner Barbeque (G4DXBV) & Beefmaster Deluxe Six Burner
Barbeque (G6DXBV): Before you start, check that you have all the contents as below.
Remove all items including any packing materials from the firebox and hood
assembly. Discard any packaging materials and protective coatings once you have
accounted for all the parts.
Firebox & Hood Assembly
Rotisserie Set
Motor Bracket
Hotplate
Two Cooking Grills
Folding Warming Rack
DC Motor
AAA 1.5V Battery
AC Transformer
Ignition Module
Motor 240V Adaptor
Cart Top Panel /
Separator Panel
Two Grease Channeling
Tray Support Brackets
Grease Channeling Tray
Grease Cup
Foil Dish
Four x Ceramic Tiles (4B)
Eight x Ceramic Tiles (6B)
One Ceramic Tile Rack (4B)
Two Ceramic Tile Racks (6B)
Two M6*60mm Screws
Four M6*16mm Screws
Seven M6*12mm Flat
Head Screws
Eight M4*8mm Screws
Two M6 Nuts
Eight M6 Washers
Six Spring Washers
Two Spare Silicone
Washers
NG Injectors 1.7mm
Four for 4B;
Six for 6B
NG Injector Cap 1.54mm
Contents list. Carefully unpack the carton and check all the parts:
