Barbeques Galore BEEFMASTER G4DXBV - Cavity Required Width and Depth; BBQ Dimensions and Required Height

Page 6
BBQ DIMENSIONS AND REQUIRED HEIGHT
≥345 mm≥520 mm
≥920 mm (for Propane only)
620.3mm
WALL
9kg
cylinder
Cylinder compartment ventilation
587mm
≥ 72mm (for hood to open)
192.5mm
177.9mm
177.9mm
620.3mm
72mm
548.3mm
548.3mm
Min 895 mm, Max 900 mm (4B)
Min 1215 mm, Max 1220 mm (6B)
Min 575 mm, Max 580 mm (2B)
98.8mm
Min 50 mm gap behind the bbq for ventilation!
2B 558 mm
4B 878 mm
6B 1198 mm
CAVITY REQUIRED WIDTH AND DEPTH
100mm
2-100mm
Min 50mm gap behind the bbq
for ventilation!
284 mm
