Page 15
STEP 3 (FOR DELUXE MODELS 4B AND 6B ONLY): Attach the rear burner ignitor
WHAT YOU NEED
One ignition module and cover box
One AAA 1.5V battery
(a) Open the cap of the Ignition Module and insert the Battery with the positive terminal
outwards as shown.
(b) The Cover Box has two flat tabs. Slide the tab into the flat bracket on the underside of the
separator panel until the cover box is firmly in place.
These next two steps assume that you have already assembled the cart using the
instructions included separately with the cart. (For build-in or island models, skip
now to STEP 7.)
STEP 4 (CART MODELS ONLY): Fix the cart/ cabinet separator panel into place.
WHAT YOU NEED
Six M6*12mm Flat Head Screws (2B)
Seven M6*12mm Flat Head Screws (4B,6B)
Assembly instructions (continued)
To Next Page
