Page 16
(a) If the cart Door Beam is already attached, detach it by removing the four screws
as shown.
门横梁
(b) Locate the Cart Top Panel in place and fix it to the cart, using two M6*12mm
screws each side and three screws at the back as shown. (Note that 2B has only
two screws at the back). Don’t fully tighten the screws yet.
(c) Refit the Door Beam into place using the four screws aside from part (a). Once the
Door Beam is in place, fully tighten all the screws holding the cart Top Panel and
the Door Beam.
门横梁
Door Beam
Door Beam
Assembly instructions (continued)
To Next Page
