3. Display installation
Overview
The panel, standard attached to a stand, is compatible with the VESA 100 mm standard. Thus, it can be
used with an arm that is approved by VESA. This chapter shows you how to release the panel from the
stand and how to attach it to an arm. If you’re not using an arm, you can skip this chapter.
1. Gently pull open both lower sides of the cover.
2. Slide the cover upwards while holding the lower sides pulled open.
3. Lift the plastic frame that covers the fixation of the panel to the stand. Turn it for 45 degrees to uncover
the fixation screws.
K5902031 CORONIS FUSION 10MP 28/08/2013 13
