Barco MDCG-10130 User Manual

5. Advanced operation
HDR2
HDR2 is a Barco specific mode featuring 10-bit
video encoding following the High Dynamic Range
(HDR) standard but allowing full refresh rate (which
is not always possible with HDR1). This mode is
usually used on color displays.
Dual 10 (only with Barco display controller) Dual 10 is a Barco specific 10-bit video encoding
mode which is usually used on grayscale displays
and which allows full refresh rate.
Automatic
When selecting this option, your Coronis Fusion
10MP will automatically assign the correct video
encoding settings to the connected video input
signals.
To manually select a video encoding mode:
1. Bring up the OSD main menu.
2. Navigate to the Configuration > Image Sources > (Left/Right) Image Source menu.
3. Enter the Video Encoding submenu.
4. Select one of the available video encoding modes and confirm.
5.21 Grayscal e con versio n mode s
Your Coronis Fusion 10MP displa y automatically detects the connected vi deo input
signals and applies the correct grayscale conversion settings. Manually selecting a
grayscale conversion mode is poss ible, but then your dis play’s image s ource selection
mode should be set to allow this. Please refer to "Image source se lection modes",
page 26 to do this.
About grayscale conversion modes
Grayscale conversion modes specify how color generated on the display controller is converted to
grayscale in your display.
The available grayscale conversion modes are:
No Conversion
Use Red Channel This mode is intended for grayscale displays where
gray is sent over the red channel.
Use Green Channel This mode is intended for grayscale displays where
gray is sent over the green channel.
Use Blue Channel This mode is intended for grayscale displays where
gray is sent over the blue channel.
Use All Channels This mode is intended for grayscale displays where
gray is sent over the red, green and blue channel.
This is done by means of a standard conversion
mechanism where 30% red, 59% green and 11%
blue are used to generate gray.
To manually select a grayscale conversion mode:
1. Bring up the OSD main menu.
2. Navigate to the Configuration > Image Sources > (Left/Right) Image Source menu.
3. Enter the Grayscale Conversion submenu.
4. Select one of the available color conversion modes and confirm.
28
K5902031 CORONIS FUSION 10MP 28/08/2013
