5. Advanced operation
5.19 Video inp ut signals
Your Coronis Fusion 10MP display automatically detects the connected video input sig-
nals. Manually selecting image source video input signals is possible, but then your
display’s image s ource selection mode should be set to allow this. Please refer to "Im-
age source selection modes", page 26 to do this.
About input signals
The available input signals for your display are:
DisplayPort 1 The input corresponding to the DisplayPort 1
connector.
DVI 1 The input corresponding to the DVI 1 connector.
DisplayPort 2 The input corresponding to the DisplayPort 2
connector.
DVI 2 The input corresponding to the DVI 2 connector.
Automatic Selection
The input is automatically selected.
To manually select a video input signal:
1. Bring up the OSD main menu.
2. Navigate to the Configuration > Image Sources > (Left/Right) Image Source menu.
3. Enter the Input Signal submenu.
4. Select one of the available input signals and confirm.
5.20 Video enco ding modes
Your Coronis Fusion 10 MP display automatically detects
the connected video input sig-
nals and applies the correct video encoding settings. Manuall y selecting a video encod-
ing mode is possible, but then your display’s image source selection mode should be
set to allow this. Please refer to "Image source selection modes", page 26 to do this.
About video encoding modes
Video encoding modes specify how the color and luminan
ce information is encoded in the video signal.
In consumer displays, this is usually done by a limited 8-bit encoding mechanism. Your Coronis Fusion
10MP however, features 10-bit encoding enabling it to better match the DICOM defined grayscale range.
Such an extensive range is necessary to comply with the guidelines set forward by the latest medical
guidelines.
The available video encoding modes for your display are listed below.
Please note that the display controller connected to your display might not always sup-
port all these v ideo encoding modes.
Standard
This mode uses the standard 8 bit encoding
mechanism.
HDR1
This mode features 10-bit video encoding following
the High Dynamic Range (HDR) standard, usually
used on color displays.
K5902031 CORONIS FUSION 10MP 28/08/2013 27
