5. Advanced operation
Enabling the USB endpoint is only recommended when you are using a non-Barco dis-
play controlle r. If you are using a Ba rco display controller, this communic ation will au-
tomatically be done over the connected video cable(s).
To enable/disable U SB :
1. Bring up the OSD main menu.
2. Navigate to the Configuration > Connectivity menu.
3. Enter the USB submenu.
4. Select Enabled/Disabled as desired and confirm.
5.10 DPMS mode
About DPMS mode
Enabling the Display Power Management System (DPMS) mode on your display will optimize its diagnos-
tic lifetime by automatically switching off the backlight when the display is not used for a specified period
of time. By default, DPMS mode is enabled on your display, but it also needs to be activated on your
workstation. To do this, go to the “Power options properties” window of your workstation.
Barco recommends setting DPMS activation after 20 minutes of non-usage.
To enable/disable DPMS mode on your display:
1. Bring up the OSD main menu.
2. Navigate to the Configuration > Power Management menu.
3. Enter the DPMS Mode submenu.
4. Select Enabled/Disabled as desired and confirm.
5.11 Lu min a nce target
About the luminance target
The luminance target of your Coronis Fusion 10MP is adjustable over a predefined range. When you
change the luminance target, the display will adjust its backlight to reach the target.
To set the luminance target:
1. Bring up the OSD main menu.
2. Navigate to the Configuration > Calibration menu.
3. Enter the Luminance Target submenu.
4. Set a luminance target value as desired and confirm.
The default value is 500 cd/m². The five year warranty is valid for this setting.
22 K5902031 CORONIS FUSION 10MP 28/08/2013
