Ch. Function Value Default Actions
128 - 135 Select input 6: Quad SDI input (if held for 1 second)
18
136 - 143 Select input 7: Quad DP board Input A (if held for 1
second)
19
144 - 151 Select input 8: Quad DP board Input B (if held for 1
second)
19
152 - 159 Select input 9: Quad DP board Input C (if held for 1
second)
19
160 - 167 Select input 10: Quad DP board Input D (if held for 1
second)
19
168 - 175 Select input 11: Quad DP board Inputs A-B (if held for
1 second)
19
176 - 183 Select input 12: Quad DP board quad column mode
(if held for 1 second)
19
184 - 255 Reserved for future functionality
5 Focus (MSB) 0 - 255 128 Set coarse lens focus adjustment
20
6 Focus (LSB) 0 - 255 128 Set fine lens focus adjustment
20
7 Zoom (MSB) 0 - 255 128 Set coarse lens zoom adjustment
20
8 Zoom (LSB) 0 - 255 128 Set fine lens zoom adjustment
20
9 Lens shift vertical
(MSB)
0 - 255 128 Set coarse lens shift in vertical direction
10 Lens shift vertical
(LSB)
0 - 255 128 Set fine lens shift in vertical direction
11 Lens shift
horizontal (MSB)
0 - 255 128 Set coarse lens shift in horizontal direction
12 Lens shift
horizontal (LSB)
0 - 255 128 Set fine lens shift in horizontal direction
13 Light Source
Power
21
0 0 Set light source to 100%
1 - 61 Set light source to value From 100% to 40% in 1%
reductions (e.g. 11 is 90%, 26 is 75%, etc)
64 Set light source to 35%
67 Set light source to 30%
70 Set light source to 25%
73 Set light source to 20%
76 Set light source to 15%
79 Set light source to 10%
80 - 87 Power on / Light source on (If held for 5 seconds)
88- 95 Power down / Light source off (if held for 5 seconds)
96 - 255 Reserved for future functionality
14 Various 0 - 7 0 Reserved for future functionality
8 - 15 Calibrate lens zoom & focus (if held for 5 seconds)
16 - 23 Calibrate lens horizontal and vertical shift (if held for 5
seconds)
DMX chart
20. Only when lens has been calibrated
21. If the Light Source is forced to an output below its minimum value, it will remain at its minimum output value
