Barco UDX User Manual

27R5906112 /15 UDX
Image 2–8 Example of connecting an HDMI source.
2. Check if the SYNC LED lit up ORANGE (reference 1). This indicates that the sync is detected on the input
signal.
1
Image 2–9
Select the source
1. Press the Input button (reference I ) on the remote control or local keypad.
I
I
Image 2–10
The Source selection menu opens on the LCD display.
Getting started
