for RS485:
Barionet100 R6 IO12 X8
Pin 4 of J7 Pin 2 of J1 Pin 2 of J11 Pin 2 of J3
Pin 5 of J7 Pin 3 if J1 Pin 3 of J11 Pin 3 of J3
for power :
The extensions can be powered from the Barionet directly, but they should
be powered separately when they are too far away from the Barionet or
require a different voltage or the Barionet power supply is not strong enough.
Barionet100 R6 IO12 X8
Pin 15 of J6 Pin 4 of J1 Pin 1 of J5 Pin 4 of J3
Pin 16 of J6 Pin 5 of J1 Pin 3 of J5 Pin 5 of J3
5.2 Required BCL application for Barionet
That a Barionet can communicate with one or more connected Barionet
extension units, it needs a BCL application loaded on the Barionet.
Barix has developed many BCL applications which can be used as they are
or they can be used also as base for your own development (source code
mostly included).
Here are examples of existing BCL applications e.g.:
- to control upto 15 R6 devices
- to control two X8 devices (inclusive analog values)
- to control upto 7 extensions (R6, X8 or IO12 – no analog)
These applications and some more can be found on: www.bcl-
applications.info
