Barko Hydraulics 930 - Towing Procedures

page 56page 56
page 56page 56
page 56
930/937 Mulcher (O)
800-00256
TOWING WITH ENGINE RUNNINGTOWING WITH ENGINE RUNNING
TOWING WITH ENGINE RUNNINGTOWING WITH ENGINE RUNNING
TOWING WITH ENGINE RUNNING
The Barko 930/937 Mulcher tractors can be towed when
the ENGINE IS NOT DISABLED by:
- Towing only while engine is running.
- Putting the transmission gear shift lever, located on
the left side of the operator seat, in NEUTRAL.
- Releasing the parking brake by pushing the switch
down located in the dash
- Lifting attachment off the ground.
Towing is only recommended at low speeds (1-2 MPH
maximum) and for short distances!
TOWING WITH ENGINE DISABLEDTOWING WITH ENGINE DISABLED
TOWING WITH ENGINE DISABLEDTOWING WITH ENGINE DISABLED
TOWING WITH ENGINE DISABLED
The Barko 930/937 Mulcher tractors are equipped with a
spring apply- pressure release disc brake on the front
drive shaft. This brake requires 100 psi of pilot pressure
to release.
In the event of a system failure, that DISABLES THE
ENGINE or prevents the parking brake release from
being activated, the tractor can NOT be towed without
removal of the front drive shafts. Both shafts must be
removed in order to allow the machine to roll freely.
TOWINGTOWING
TOWINGTOWING
TOWING
CAUTION CAUTION
CAUTION CAUTION
CAUTION
Towing machine with brake activated canTowing machine with brake activated can
Towing machine with brake activated canTowing machine with brake activated can
Towing machine with brake activated can
destroy the brake.destroy the brake.
destroy the brake.destroy the brake.
destroy the brake.
FRONT DRIVEFRONT DRIVE
FRONT DRIVEFRONT DRIVE
FRONT DRIVE
SHAFTSSHAFTS
SHAFTSSHAFTS
SHAFTS
BRAKEBRAKE
BRAKEBRAKE
BRAKE
ChocksChocks
ChocksChocks
Chocks
Extreme caution must be taken while removing the drive
shafts as this disables the brake system and the tractor
can roll free
All wheels should be blocked securely prior to removing
the drive shafts and when reinstalling the drive shafts to
prevent injury or loss of life to the service technician.
Extreme caution should be taken while towing the
machine with the drive shaft removed as there will be no
ability to brake the machine!
Towing the machine with the drive shaft removed should
be limited to very low speeds and limited distances!
WARNING WARNING
WARNING WARNING
WARNING
With brake disconnect, machine is allowed to rollWith brake disconnect, machine is allowed to roll
With brake disconnect, machine is allowed to rollWith brake disconnect, machine is allowed to roll
With brake disconnect, machine is allowed to roll
freely and can cause severe injury or death.freely and can cause severe injury or death.
freely and can cause severe injury or death.freely and can cause severe injury or death.
freely and can cause severe injury or death.
