The Power View is a multifunction display that is tied in directly to the engine protection system. It is used to display
engine operating parameters and to show active fault codes as well as fault code history. A list of fault codes follows
this section. There are three different levels of fault codes displayed by the Power View. A symbol indicates an
auxiliary gage fault, meaning the engine is within standard operating specifications but a gage has failed. It is safe to
continue operation of the loader but the gage should be replaced as soon as possible. A symbol indicates a
fault warning, meaning the engine is out of standard operating specifications. It is safe to continue operation but
adjustments should be made to allow engine to go back to standard operating specifications. A symbol indicates
a shutdown or derate condition, meaning the engine is out of standard operating specifications to the extent that
extended operation could result in engine damage. The Power View will display a shut down message and derate the
power/speed of the engine until standard conditions are met.
The monitoring system is programed with the standard configuration that will
not not
not not
not shut the engine down if operating
conditions are out of range, the engine will only derate the power/speed. The engine can be reconfigured to include
the shutdown option using the Insite service tool.
The following are parameters that can be selected to be displayed through the custom setup menu (all items are
always monitored), some items are not applicable and will give a zero reading.
ENGINE PARAMATERSENGINE PARAMATERS
ENGINE PARAMATERSENGINE PARAMATERS
ENGINE PARAMATERS
SENSOR INCLUDEDSENSOR INCLUDED
SENSOR INCLUDEDSENSOR INCLUDED
SENSOR INCLUDED
• Accelerator pedal position No
• Percent load at current RPM Yes
• Actual engine torque Yes
• Engine speed Yes
• Trip distance No
• Total vehicle distance No
• Total engine hours Yes
• Trip fuel No
• Total fuel used Yes
• Engine coolant temperature Yes
• Fuel temperature No
• Machine hours Yes
• Barometric pressure Yes
• Fan drive No
• Boost pressure Yes
• Engine oil pressure Yes
• Intake temperature Yes
• Electrical potential Yes
• Wheel based vehicle speed No
• Fuel rate Yes
• Instantaneous fuel economy Yes
• Average fuel economy Yes
!
!
!
