Basler racer User Manual

AW00118508000 Camera Functional Description
Basler racer Camera Link 30
Fig. 10: CMOS Sensor Architecture. Type A is a 2k Sensor or 2k Sensor Segment with a Pixel Size of 7 µm x 7 µm
and Type B is a 4k Sensor Segment with a Pixel Size of 3.5 µm x 3.5 µm.
CMOS Sensor
Analog Processing
Digital Processing
Pixels
ADCs
Digitized Pixel Data; 2 x 12 Bit
Digital Processing
Digital Processing
ADCs
ADCs
Analog Processing
Analog Processing
CMOS Sensor
Pixels
Type A
Type B
Digitized Pixel Data (Even-numbered Pixels);
2 x 12 Bit
Digitized Pixel Data (Odd-numbered Pixels);
2 x 12 Bit
