Baudoulin 4M11G User Manual

Maintenance Manual of 4M11 Series Diesel Engine For Land Power Generators

114
Appendix C Tightening Torques for Main Bolts
Bolt name
Bolt
specification
Control value
(N.m)
Inspection value
(N.m)
Fastening bolt for intake and exhaust pipes M10 45～50 45～60
Flywheel bolt M16-10.9 285～295 285～340
Fastening bolt for crankshaft hub M16-12.9 300～310 300～360
Fastening bolt for shock absorber M10-10.9 65～70 65～80
Fastening bolt for camshaft gear M10×1.25-12.9 85～90 85～110
Fastening bolt for gears between camshaft
and fuel injection pump
M8-12.9 55～60 55～70
Fastening bolt for fuel injection pump gear
(Euro-II engine)
M10-10.9 65～70 65～80
Nut on fuel injection pump shaft
Nut on fuel injection pump shaft
M14×1.5 85～100 85～110
M18×1.5 100～110 100～120
Hexagon bolt and stud for flywheel
housing
M12-12.9 140～145 140～170
M10-12.9 80～85 80～95
Fastening bolt for oil sump
Cylindrical head bolt for cast carrying oil
sump
M8-8.8 20～25 20～35
M8-10.9 30～35 30～45
Fastening bolt for double-stage balance
mechanism
M8-8.8 20～25 20～35
Fastening bolt for engine oil pump
Stud with lock nut
M8-12.9 30～40 30～50
M8-8.8 20～25 20～35
Rocker seat bolt M10-8.8 40～45 40～55
Rocker adjustment nut M9×1 20～25 20～35
Fastening bolt for cylinder head cover M8-8.8 10～15 10～25
Lock nut of high pressure fuel pipe M14×1.5 20～25 20～35
Fastening nut for fuel injector
Fastening bolt for fuel injector (Euro-II
engine)
M8-8.8 10～15 10～25
M10×1.25-10.9 80～85 80～95
Fastening bolt for pulley on wheel hub
M8-8.8 45～50 45～60
M10-10.9 65～70 65～80
M12-8.8 85～90 85～100
Fastening bolt for hydraulic pump
M8-10.9 30～35 30～45
M10-10.9
60～65 60～75
