Baxi ECOGEN 24/1.0 Installation & Servicing Instructions

 AIRDUCT
 Equivalent
LengthValue
Noof
fittings/pipes
Subtotal
1mextension 1m 5 5.0m
135°bend 0.25m 2 0.5m
91.5°bend 0.5m 2 1.0m
 EquivalentLengthAirDuct=6.5m
 FLUEDUCT
 Equivalent
LengthValue
Noof
fittings/pipes
Subtotal
1mextension 1m 5 5.0m
135°bend 0.25m 2 0.5m
91.5°bend 0.5m 2 1.0m
 EquivalentLengthFlueDuct=6.5m
page25
8.3FlueAccessories

Key Accessory Size CodeNo
FLUEGROUPA
ConcentricFlueSystem100mmdiameter
A3 TelescopicInternalFlueKit 315500mm 5119654
A2 TelescopicFlue(inclelbow)  5118069
A HorizontalFlueTerminal(inclelbow)  5118489
B FlueExtension 1000mm 5111074
C FlueBend 93° 5111075
D FlueBend(pair) 135° 5111085
U PipeSupport(painted) 100mmØ 5111080
P WallLiner  5111067
S FlueTerminalDeflector  5111068
FLUEGROUPN
TwinFlueSystem80mmdiameter
E FlueExtension(pair) 1000mm 5111087
F FlueBend(pair) 90° 5111072
G FlueBend(2pair) 135° 5111086
J VerticalFlueBoilerAdaptorKit  5111079
H VerticalFlueAdaptor  5111084
W PipeSupport(pair) 80mm 5111081
FLUEGROUPA,N,G
VerticalFlueKits
K VerticalFlueTerminal(80/125usewithItemH)  5111078
K1 VerticalFlueTerminal(60/100)  5118576
L PitchRoofFlashing 25°/50° 5122151
M RoofCoverPlate  246143
N FlatRoofFlashing  246144
