Baxi ECOGEN 24/1.0 Installation & Servicing Instructions

Allfluesystemsmustbesecurelysupportedatleastonceeverymetre.
Suitablepipesupportsareavailableasaccessories.
VerticalFlues(TwinPipe)
VerticalFlues
TotalEquivalentLength=
A+B+C+1x90°Bend
Allverticalandangledrunsmustbeincluded,measuredfromtheboileradaptor
(pointX)tothejointwiththeflueterminal(pointY).
One91.5°bendortwo135°bendscanbeincludedwithoutreductionofthefluelength.
Iffurtherelbowsarerequiredthefluelengthmustbereducedbythefollowingamounts:
1metreforeach91.5°bend
0.5metreforeach45°bend
