Baxi POWER HT+ Series - Page 121

3. Lift the two side panels on the low-loss header kit.
4. Pull the two side panels on the low-loss header kit to remove them.
5. Remove the lower insulating shell.
6. Remove the magnetic ring.
7. Place a container with sufficient capacity underneath the low-loss
header vent valve.
8. Open the vent valve, using the plug.
9. Allow the flow to continue until no more dirt is present.
Fig.181
MW-4000302-1
4
3
Fig.182
MW-4000303-1
5
6
Fig.183
MW-4000304-1
7
8
11 Maintenance
7702630 - v02 - 11082018 POWER HT + 121
