071960491 COLLEAGUE CXE VOLUMETRIC INFUSION PUMP OPERATOR’S MANUAL 2-9
Description Display Reference Guide
Color Reference Guide
Table 2-4 describes the meaning of the colors used on the device and
displays.
Display Reference Guide
The Main Display provides two types of screens: the main display
screen and programming screens.
Audio speaker and beeper Generate alert and alarm tones.
Mounting clamp and knob Secures the pump to a pole.
Manual tube release Flip-out knob for manual tube unloading.
PANEL LOCKOUT button
The Panel Lockout button disables all the front panel keys except the Main
Display
, Volume History, Channel Select (for triple channel pumps only), and
Back Light
keys, and the Options, Primary, and Secondary soft keys for
viewing.
Table 2-3 Rear Panel Features — continued
Item Description
Table 2-4 Pump and Display Colors
Color Description
Yellow Yellow is used to call attention to a condition. Infusion program information is yellow. Yellow is
used in the display status line to indicate an alert condition. The ALERT LED on the pump head
module is yellow.
Red Red is used to indicate a serious condition or stop. Red is used in the display status line to indicate an
alarm or failure condition. The red stop sign icon indicates that an infusion is stopped. The ALARM
LED and the STOP key on the pump head module are red.
Green Green is used to indicate normal operation or start. The green drop icon indicates that an infusion is
running. The RUNNING LED on the pump head module and the START key on the pump are green.
White White is used for all basic information on the programming and main display screens, and as a
background color for the prompt line and some pop-ups. Also used for the Lock icon and the Flow
Check icon.
Dark blue Dark blue is used as the background color for all programming and main display screens.
Light blue Light blue is used for the secondary icon.
Black Black text is used on a yellow background to describe alert conditions.
