BBK DK1410SI - Chapter Six BOM List

MATERIAL
CODE
MATERIAL NAME SPECIFICATIONS LOCATION
2100017 LEAD F0.6 SHAPED 20mm W1,W2
2100003 LEAD F0.6 SHAPED 7.5mm W3,W7,W8,W9,W10
2100004 LEAD F0.6 SHAPED 10mm W4,W5,R514
2100007 LEAD F0.6 SHAPEN 15mm W6
0000274 CARBON FILM RESISTOR 1/4W47O±5% SHAPED 10 R517
0000431 CARBON FILM RESISTOR 1/4W75O±5% SHAPED 10 R505
0000362 CARBON FILM RESISTOR 1/4W220O±5% SHAPED 10 R511
0000282 CARBON FILM RESISTOR 1/4W820O±5% SHAPED 10 R513
0000284 CARBON FILM RESISTOR 1/4W1.5K±5% SHAPED 10 R523
0000289 CARBON FILM RESISTOR 1/4W4.7K±5% SHAPED 10 R510
0000294 CARBON FILM RESISTOR 1/4W10K±5% SHAPED 10 R507
0000301 CARBON FILM RESISTOR 1/4W47K±5% SHAPED 10 R506,R522
0000310 CARBON FILM RESISTOR 1/4W1MO±5% SHAPED 10 R504
0000651 CARBON FILM RESISTOR 1/2W 430O±5% SHAPED 12.5 R512
0010062 METAL FILM RESISTOR 1/4W2.2K±1% SHAPED 10 R521
0010063 METAL FILM RESISTOR 1/4W4.7K±1% SHAPED 10 R509
0010101 METAL FILM RESISTOR 1/4W12K±1% SHAPED 10 R508
0010273 METAL FILM RESISTOR 1/4W24K±1% SHAPED 10 R520
0010279
METAL OXIDE FILM
RESISTOR
1W680K±5% SHAPED 15 R501
0010226
METAL OXIDE FILM
RESISTOR
1/2W22O±5% SHAPED 12.5 R529
0010275
METAL OXIDE FILM
RESISTOR
1W33O±5% SHAPED VERTICAL 7.5 R518,R519
0010147
METAL OXIDE FILM
RESISTOR
2W47K±5% SHAPED FLAT 15×7 R516,R515
0010157
METAL OXIDE FILM
RESISTOR
2W68K±5%SHAPED FLAT 15×7 R502,R525
0010263
METAL OXIDE FILM
RESISTOR
2W75K±5% SHAPED FLAT 15×7 R503,R524
0010281
METAL OXIDE FILM
RESISTOR
3W1K±5% SHAPED VERTICAL 7.5 R530
0010288
METAL OXIDE FILM
RESISTOR
1W100O±5% SHAPED VERTICAL 7.5 R527
0200105 PORCELAIN CAPACITOR 50V 100P±10% 5mm C504,C507,C509,C511,C512,C518,C519
0200123 PORCELAIN CAPACITOR 50V 102±10% 5mm C513,C520
0200134 PORCELAIN CAPACITOR 50V 223±20% 5mm C503
POWER BOARD 5447883
Chapter six BOM List
DVD HOME THEATER DK1410SI(RU)
- 112 -
