MATERIAL
CODE
MATERIAL NAME SPECIFICATIONS LOCATION
0200138 PORCELAIN CAPACITOR 50V 104±20% 5mm C502,C514,C517,C521
0200224 PORCELAIN CAPACITOR 1000V 103 +80%-20% 7.5mm C501,C516
0210158
TEMETAL OXIDE FILM
RESISTORLENE CAPACITOR
100V 472±10% SHAPED 5mm C506,C508,C510,C515
0210024
TEMETAL OXIDE FILM
RESISTORLENE CAPACITOR
100V 333±10% 5mm C505
0210148
TEMETAL OXIDE FILM
RESISTORLENE CAPACITOR
100V 473±10% SHAPED 5mm C523,C522
0210204 ANTI-JAMMING CAPACITOR @MKP61 X2 275VAC 104M 15 UL XC501,XC502
0200353 CERAMIC CAPACITOR @Y1 400VAC 102±10% 10mm UL YC501,YC502
0260749 CD EZ 400V220U±20% 30×30 10 TC501
0260664 CD CD11K 16V220U±20% 6.3×11 2.5 TC510
0260653 CD CD11K 16V470U±20%8×14 3.5 TC505
0260597 CD
CD11 105℃ 16V1000U±20%10×20 5
TC506,TC507
0260654 CD CD11K 16V2200U±20% 10×25 5 TC508,TC509
0260558 CD CD11T 25V470u±20%10×16 5 TC504,TC512
0260665 CD CD11K 25V1000U±20% 13×20 5 TC503
0260667 CD CD11K 50V1U±20% 5×11 2 TC513
0260663 CD CD11K 35V220U±20% 8×12 3.5 TC511
0260666 CD CD11K 50V47U±20% 6.3×11 2.5 TC514
0260601 CD
CD11C 105℃ 50V22U±20%6×7 2.5
TC502
0260668 CD CD11K 50V470U±20% 13×20 5 TC517
0260751 CD CD11K 50V1000U±20%16×25 7.5 TC515,TC516
0390154
MAGNETIC BEADS
INDUCTOR
RH-357508 L502
0390340 VERTICAL INDUCTOR 10uH±10% 5A 12.5×26.5 10mm L506
0410010 CHOKE COIL VERTICAL 10UH 1A 5mm L505
0410011 CHOKE COIL VERTICAL 10UH 2A 5mm L503,L504
1000010 POWER GRID FILTER JBL2822 30mH±20% L501
0460513
SWITCH POWER
TRANSFORMER
@BCK-28-0563 VDE T501
0460514
SWITCH POWER
TRANSFORMER
@BCK-40-0244 VDE
T502 ①
0460515
SWITCH POWER
TRANSFORMER
@BCK-40-0726 UL
T502 ①
0680065 SCHOTTKY DIODE SR560 DO-27 SHAPED 20mm D504,D505
0570006 DIODE 1N4148 D502
0570013 DIODE HER105 D503,D506,D507,D509
