MATERIAL
CODE
MATERIAL NAME SPECIFICATIONS LOCATION
0000540 CARBON FILM RESISTOR 1/2W150O±5% SHAPED 12.5 R121,R117
0260025 CD CD11 16V47U±20%5×11 2 C108
0260200 CD CD11C 16V47U±20%5×7 2 C109
0570006 DIODE 1N4148 VD101~VD104
0620040 RADIATION DIODE 3B 4SC WHITE ISSUE BLUE VD105
0780030 TRIODE 8550C V100
0882131 IC S0793GB QFP
N102 ⑨
0882364 IC PT6315 LQFP
N102 ⑨
0160201 DIGITAL POTENTIOMETER EC12P24L25F12 RP100
1200653 DISPLAY SCREEN HL-D593
DS100 ⑩
1200531 ISPLAY SCREEN VFD16-0801
DS100 ⑩
1200532 DISPLAY SCREEN HNV-08SS56
DS100 ⑩
1340064
LIGHT TOUCH RESTORE
SWITCH
KFC-A06-2WB L3.8 S100~S106
1340003
LIGHT TOUCH RESTORE
SWITCH
HORIZONTAL 6×6×1 S107
1980030 MICROPHONE SOCKET CK3-6.35-19 MC100,MC101
2121911 FLAT CABLE
6P120 2.5/2.0 2 PIN,WITH
NEEDLE,TOGETHER DIRECTION
XP201
2121913 FLAT CABLE
5P320 2.5 2 PIN,WITH
NEEDLE,TOGETHER DIRECTION
XP505
2121912 FLAT CABLE
6P330 2.5 2 PIN,WITH
NEEDLE,TOGETHER DIRECTION
XP106
2121615 FLAT CABLE
7P280 2.5 2 PIN,WITH L
NEEDLE,TOGETHER DIRECTION
XP204
2360024 IR SENSOR LTOP-4338
N103 ⑾
2360021 IR SENSOR AT138BV3
N103 ⑾
5233065 SOFT SPONGE SPACER 8×8×10 DOUBLE-FACED,HARD SURFACE CONTROL BOARD
5232691 SOFT SPONGE SPACER 15×10×9 DOUBLE-FACED,HARD SURFACE CONTROL BOARD
5445683
PCB SEMI-FINISHED
PRODUCT
6DVR938-5-SMD DK1010S-2
0090149 SMD RESISTOR 1/10W 47O±5% 0805 R122
0090193 SMD RESISTOR 1/16W 82K±5% 0603 R120
0090181 SMD RESISTOR 1/16W 100O±5% 0603 R123~R126
0090019 SMD RESISTOR 1/16W 4.7K±5% 0603 R115,R116,R127,R128,R129
SURFACE CONTROL BOARD 5445684
DVD HOME THEATER DK1410SI(RU)
SURFACE CONTROL BOARD SMD 5445683
