MATERIAL
CODE
MATERIAL NAME SPECIFICATIONS LOCATION
0090023 SMD RESISTOR 1/16W 10K±5% 0603 R118,R119,R133
0310066 SMD CAPACITOR 50V 102±10% X7R 0603 C112,C113
0310207 SMD CAPACITOR 50V 104 ±20% X7R 0603
（SURFACE CONTROL
BOARDC111,C110,C107） ⑿
0310543 SMD CAPACITOR 50V 104±10% X7R 0603
（SURFACE CONTROL
BOARDC111,C110,C107） ⑿
0310195 SMD CAPACITOR 50V 221±10% X7R 0603 C114,C115,C116
1632035 PCB 6DVR938-8
0390057
MAGNETIC BEADS
INDUCTOR
RH354708 L100,L102~L105,L118~L122
0780028 TRIODE 8050C(120-200) TO-92 V100~V102
1910158 TERMINAL SOCKET AV4-8.4-13 XC103
1910182 TERMINAL SOCKET AV4-8.4-13/PB-25 XC104
1860059 SCART SOCKET CS-111 XC107
1910159 TERMINAL SOCKET CS TERMINAL DASW-02 XC105
1090024
ELECTRO-OPTIC
TRANSFORMER
TX179AT
XC106 ⒀
1090077
ELECTRO-OPTIC
TRANSFORMER
TX179AT-2
XC106 ⒀
1090045
ELECTRO-OPTIC
TRANSFORMER
TX179ATW
XC106 ⒀
2150286 FLAT CABLE
8P120 2.5 T2 2×2P SHIELD WITH
NEEDLE,TOGETHER DIRECTION
XP401
2121533 SOFT FLAT CABLE
13P300 2.5/2.0 2 PIN,WITH
NEEDLE,TOGETHER DIRECTION
XP206
0090005 SMD RESISTOR 1/16W 33O±5% 0603 R114
0090006 SMD RESISTOR 1/16W 75O±5% 0603 R107~R110,R116
0090008 SMD RESISTOR 1/16W 220O±5% 0603 R129
0090009 SMD RESISTOR 1/16W 330O±5% 0603 R104
0090014 SMD RESISTOR 1/16W 1K±5% 0603 R115
0090017 SMD RESISTOR 1/16W 2.2K±5% 0603 R112,R113
0090019 SMD RESISTOR 1/16W 4.7K±5% 0603 R111
0090034 SMD RESISTOR 1/16W 100K±5% 0603 R130
0090238 SMD RESISTOR 1/16W 68O±5% 0603 R103
0310045 SMD CAPACITOR 50V 47P±5% NPO 0603 C108~C117
0310066 SMD CAPACITOR 50V 102±10% X7R 0603 C102,C103,C118,C119
0310085 SMD CAPACITOR 50V 20P±5% NPO 0603 C121~C126,C183~C188
DVD HOME THEATER DK1410SI(RU)
INPUT OUTPUT BOARD 5447889
