MATERIAL
CODE
MATERIAL NAME SPECIFICATIONS LOCATION
0310207 SMD CAPACITOR 50V 104 ±20% X7R 0603
C120,C129 ⒁
0310543 SMD CAPACITOR 50V 104±10% X7R 0603
C120,C129 ⒁
0310112 SMD CAPACITOR 16V 224±10% 0603 C105
0390096 SMD INDUCTOR 1.8UH±10% 1608 L106,L107,L110,L111,L114,L116
0700007 SMD DIODE 1N4148 VD100~VD111
1631897 PCB 1DVR938-3
0010282
METAL OXIDE FILM
RESISTOR
3W1K±5% SHAPED R 20×8 R198
0260048 CD CD11 35V470U±20%10×20 5
C168,C169,C172,C173,C176,C177,C180,C
181,C185,C186
0260491 CD CD11K 35V680U±20% 13×20 5 C36,C37,C133,C134
0410176
VERTICAL SCREEN SHIELD
FILTERING INDUCTOR
10uH±10% 4A 5mm L1~L4,L9~L11
05800069
VOLTAGE REGULATOR
DIODE
5.1V±5% 1/2W BELT VD2,VD3
05800099
VOLTAGE REGULATOR
DIODE
9.1V±5% 1/2W BELT VD8
0960226
CMETAL OXIDE FILM
RESISTORSTAL OSCILLATOR
4.332MHz 49-s Y2
0960182
CMETAL OXIDE FILM
RESISTORSTAL OSCILLATOR
12.288MHz 49-S Y3
0960171
CMETAL OXIDE FILM
RESISTORSTAL OSCILLATOR
13.50MHZ 49-S Y1
0881227 IC RC4558P DIP
N1 ⒂
0880445 IC 4558C DIP
N1 ⒂
0880124 IC NJM4558D DIP
N1 ⒂
0881393 IC IL4558N DIP
N1 ⒂
0881429 IC CD4052BE DIP
N5 ⒃
0880443 IC CD4052BCN DIP
N5 ⒃
0882375 IC RC4580 DIP
N10,N11 ⒄
0882351 IC NE4580 DIP
N10,N11 ⒄
1940007 SOCKET 7P 2.5mm XS201
1940009 SOCKET 8P 2.5mm XS401
1940140 CABLE SOCKET
14P 1.0mm DUAL RANK STRAIGHT
INSERT
XS207
1940239 SOCKET 10P 2.5mm STRAIGHT FLEX XS402
1990025
EXTERNAL SOURCES
SOCKET
6PZ-7 XC100
2120174 FLAT CABLE
7P60 2.5 2 SOCKET WITH NEEDLE
TOGETHER DIRECTION
XP101
DVD HOME THEATER DK1410SI(RU)
AMPLIFIER BOARD 5447884
- 121 -
