BBK DK1410SI - Page 126

MATERIAL
CODE
MATERIAL NAME SPECIFICATIONS LOCATION
2121621 FLAT CABLE
4P90 2.5 2 PIN,WITH
NEEDLE,TOGETHER DIRECTION
XP503
3580186 RADIATOR 78×49×30 DVR938 NOT OXIDATION
4210005 MACHINE-TAPPING SCREW PM 3×8 BLACK
4450012 BOLT PAD F3×7.2×0.5
4490001 SPRING PAD F3
5230707 SOFT SPONGE SPACER 10×10×2 SINGLE-FACED,HARD
5233174 RUBBER SPACER
9×9×1 SINGLE-FACED WITH GLUE IN
REAR SIDE,CENTER HOLE f3
0090001 SMD RESISTOR 1/16W 0O±5% 0603 R199~R213,R223
0090272 SMD RESISTOR 1/16W 1O±5% 0603
R51~R53,R65,R93,R113,R144,R145,R174,
R178,R182,R187,R196,R197
0090540 SMD RESISTOR 1/16W1.5O±5% 0603 R34~R37,R134~R136,R186
0090002 SMD RESISTOR 1/16W 2.2O ±5% 0603 R68
0090616 SMD RESISTOR 1/16W 3.3O±5% 0603 R40,R41,R67,R140,R141
0090314 SMD RESISTOR 1/16W 5.1O±5% 0603 R88
0090003 SMD RESISTOR 1/16W 10O±5% 0603 R24,R25,R89,R116,R137,R175
0090004 SMD RESISTOR 1/16W 22O±5% 0603 R115
0090230 SMD RESISTOR 1/16W 47O±5% 0603
R5,R29,R56,R59,R62,R63,R69,R70,R94~R
101,R225
0090220 SMD RESISTOR 1/16W 51O±5% 0603 R27,R122
0090017 SMD RESISTOR 1/16W 2.2K±5% 0603 R1,R2,R80,R82
0090239 SMD RESISTOR 1/16W 200O±5% 0603 R64,R66
0090008 SMD RESISTOR 1/16W 220O±5% 0603 R123~R126
0090014 SMD RESISTOR 1/16W 1K±5% 0603 R3,R20,R133,R217,R218
0090019 SMD RESISTOR 1/16W 4.7K±5% 0603
R76~R79,R81,R83,R102,R103,R105,R110,
R111,R138,R139,R156,R230,R38,R42,R44
,R48,R191,R21
0090020 SMD RESISTOR 1/16W 5.1K±5% 0603 R43,R45,R49,R90,R58,R192
0090022 SMD RESISTOR 1/16W 8.2K±5%
R214,R215,R146~R149,R154,R155,R159,
R160
0090023 SMD RESISTOR 1/16W 10K±5% 0603
R6,R16,R54,R55,R57,R60,R61,R84~R87,R
92,R117,R119~R121,R142,R143,R150~R1
53,R163,R164,R166~R168,R170,R171
0090187 SMD RESISTOR 1/16W 12K±5% 0603 R14,R18
0090025 SMD RESISTOR 1/16W 20K±5% 0603
R172,R176,R180,R183,R193,R173,R177,R
181,R184,R194
0090026 SMD RESISTOR 1/16W 22K±5% 0603 R17,R165
0090027 SMD RESISTOR 1/16W 27K±5% 0603 R106~R109,R157,R158,R161,R162
0090192 SMD RESISTOR 1/16W 51K±5% 0603 R4
- 122 -
