BBK DK1410SI - Page 79

165 DACVDDB Power 3.3V power pin for video DAC circuitry
166 DACVSSB Ground Ground pin for video DAC circuitry
167 DACVDDA Power 3.3V power pin for video DAC circuitry
168 Y/G
InOut 4mA,
SR
Green, Y, SY, or CVBS
169 DACVSSA Ground Ground pin for video DAC circuitry
170 B/CB/PB
InOut 4mA,
SR
Blue, CB/PB, or SC
171 R/CR/PR
InOut 4mA,
SR
Red, CR/PR, CVBS, or SY
MISC (12)
101 PRST#
InOut
PD,SMT
Power on reset input, active low
100 ICE InOut PD,SMT Microcontroller ICE mode enable
193 XTALO Output 27MHz crystal output
194 XTALI Input 27MHz crystal input
44 GPIO0
VSYN
YUV1
InOut 4mA,
SR,SMT
33) General purpose IO 0
34) Vertical sync for video input
35) Digital video YUV output 1
45 GPIO1
HSYN
INT4#
YUV2
InOut 4mA,
SR,SMT
36) General purpose IO 1
37) Horizontal sync for video input
38) Microcontroller external interrupt 4
39) Digital video YUV output 2
46 GPIO2 SPMCLK InOut 2mA
40) General purpose IO 2
41) Audio S/PDIF SPMCLK input
147 GPIO3
INT1#
SPDATA
InOut 2mA
42) General purpose IO 3
43) Microcontroller external interrupt 1
44) Audio S/PDIF SPDATA input
148 GPIO4 SPLRCK InOut 2mA
45) General purpose IO 4
46) Audio S/PDIF SPLRCK input
150 GPIO5
INT3#
SPBCK
InOut 2mA
47) General purpose IO 5
48) Microcontroller external interrupt 3
49) Audio S/PDIF SPBCK input
90 GPIO6 YUVCLK
InOut 4mA,
SR,SMT
50) General purpose IO 6
51) Digital video clock output
