36 GND Common
37 GND Common
38 OUT-B O Left channel power amplifier output
39 OUT-B O Left channel power amplifier output
40 PVDD-B Left channel power amplifier power supply
41 PVDD-B Left channel power amplifier power supply
42 BST-B High-side bootstrap supply (BST)
43 BST-C HS bootstrap supply (BST)
44 PVDD-C 28.5V power supply
45 PVDD-C 28.5V power supply
46 OUT-C unused
47 OUT-C unused
48 GND Common
49 GND Common
50 OUT-D O Centre power amplifier output
51 OUT-D O Centre power amplifier output
52 PVDD-D Centre power amplifier power supply
53 PVDD-D Centre power amplifier power supply
54 BST-D HS bootstrap supply (BST)
55 GVDD Door drive and digital regulator power supply end
56 GND Common
3. Table 1 is shown as follows:
M1 M2 Protection mode selection
0 0 Auto error correction mode
0 1 Error detection off mode
1 0 Protection system ineffective mode
1 1 none
4. Table 2 is shown as follows:
M3 Output mode selection
0 Bridge binding load output mode
1 none
