Chapter 3: Wash Station Assembly Replacement 19
The tubing nuts are normally finger tight. If it is difficult to unscrew a
tubing nut, use a 5/16 wrench to loosen it.
6 Turn the sample injection port (see figure) slightly to disengage the
magnets, and lift the port approximately 1 inch.
7 Disconnect the silicon tubing from the sample injection port. Do not
disconnect the silicon tubing at the lower end because this could damage
the lower connector.
.
Tubing assembly
Secondary pump
