Alaris™ GP (Guardrails™) Volumetric Pump
Getting Started
BDDF00535 Issue 1
15/56
The Alaris Safety Clamp
Alaris Safety Clamp*: Safety Clamp In Non Occluded Position:
When a new infusion set is removed from packaging the Safety
Clamp will be in this position**:
Safety Clamp
Slider
Safety Clamp Frame
Safety Clamp Tab
FLOW ENABLED
Clamp in NON OCCLUDED
POSITION
Safety Clamp In Occluded Position: Manually Operating The Safety Clamp
After infusion set is loaded into the Pump, opening the door
activates door hooks which will pull the Safety Clamp slider
out, as shown:
To move the slider into the non occluded position manually, push
up Safety Clamp Tab and push Safety Clamp Slider completely
into Frame:
NO FLOW
Clamp is in OCCLUDED
POSITION
Æ
Ê
1. Push up
2. Push
w
w
• Pushing on the Safety Clamp Slider enables full set flow to the patient. Therefore it is recommended to always
close the roller clamp as well.
• However, if gravity infusion is required, push up Safety Clamp Tab and push orange Safety Clamp Slider
completely into Frame to enable flow. The gravity infusion can be regulated using the roller clamp on the set.
* Hereinafter referred to as to as 'Safety Clamp'.
** This is necessary to avoid tube damage during storage and to ensure correct sterilisation and allows immediate priming.
