Alaris™ GP (Guardrails™) Volumetric Pump
Service Configuration Mode
BDDF00535 Issue 1
28/56
Service Configuration Mode
This section comprises of a list of options which can be configured. Some can be entered via the Pump SERVICE menu (available in
Technician Mode) and others through the Alaris Editor Software.
w
Access codes should only be entered by Qualified Service Personnel.
Alarm Presets
Pumps with version 2.3.4 software have 2 alarm tones to choose from during configuration:
• ORIGINAL ALARMS: Low, medium and high priority alarm tones that sound like the auditory alarms and warnings from software
versions prior to 2.3.4
• 3RD EDITION ALARMS: Low, medium and high priority alarm tones in accordance with IEC 60601-1-8: 2012 and IEC 60601-2-
24:2012
Enter the access code on the Pump for Alarm Presets, see the Technical Service Manual or Information Notice for details.
1. Use the
f keys to select alternative alarm tones.
2. When the desired alarm tone has been selected press OK softkey.
3. When all modifications have been carried out press QUIT softkey.
w
All pumps in a single care area should be configured with the same alarm tones to avoid User confusion.
The Hospital/Facility is responsible for selecting and configuring the desired alarm scheme.
Alaris Gateway Workstation (Workstation) with software versions 1.1.3, 1.1.3 MR, 1.1.5, 1.2, 1.3.0, 1.6.0 or 1.5 do not
support the new Pump low priority visual alarms scheme defined in IEC 60601-1-8: 2012. For Pumps with version 2.3.4
software or higher docked into these Workstations there will be a mismatch of alarm priority displayed. As a result,
Near End Of Infusion, AC Power Fail, Add Drug Not Complete, and Attention alarms will display as a medium visual
priority alarms on the Workstation beacon and a low priority alarm on the Pump. Additionally, for certain information
signals, e.g. those associated with Add Drug Not Complete and Titration Not Confirmed, the Workstation beacon will
illuminate while the beacon on the pump will not. In the event of an alarm priority mismatch, the User should refer to
the alarm on the Pump for the correct priority.
Configured Options
Enter the access code on the Pump for SERVICE mode, then select CONFIGURATION, see the Technical Service Manual for details.
Use Alaris Editor to configure the Pump configuration, drug library and units enabled for each data set.
Date & Time
1. Select DATE & TIME from the CONFIGURATION menu using the f keys and press the OK softkey.
2. Press the OK softkey to confirm.
3. Use the
f keys to adjust the date displayed, pressing the NEXT softkey to access the next field.
4. When the correct date and time are displayed press the OK softkey to return to the CONFIGURATION menu.
5. Press the QUIT softkey to return to the SERVICE menu and press
ato exit and power down.
Pump Reference
This option is used to add reference text to be shown on the Pump start up display.
1. Select PUMP REFERENCE from the CONFIGURATION menu using the
f keys and press the OK softkey.
2. Use the
f keys to enter the text and NEXT to move to the next character.
3. When the desired text has been selected press OK softkey to return to the CONFIGURATION menu.
4. Press QUIT to exit back to the main SERVICE menu and press
a to exit and power down.
Language
This option is used to set the language of messages shown on the Pump display.
1. Select LANGUAGE from the CONFIGURATION menu using the
f keys and press the OK softkey.
2. Use the
f keys to select the language.
3. When the desired language has been selected press OK softkey to return to the CONFIGURATION menu.
4. Press QUIT to exit back to the main SERVICE menu and press
a to exit and power down.
