Alaris™ GP (Guardrails™) Volumetric Pump
Symbol Definitions
BDDF00535 Issue 1
8/56
Symbol Definitions
Labelling Symbols:
Symbol Description
Attention (Consult accompanying document)
x
Potential Equalisation (PE) Connector
RS232/Nursecall Connector.
l
Defibrillation-proof type CF applied part (Degree of protection against electrical shock).
IP33
Protected from solid objects greater than 2.5mm.
Protected against direct sprays up to 60° from the vertical.
r
Alternating Current
Device complies with the requirements of Council Directive 93/42/EEC as amended by 2007/47/EC.
T
Date of Manufacture
t
Manufacturer
Connector for Flow Sensor
U
Not for Municipal Waste
W
Fuse rating
+40°C
0°C
Operating Temperature Range - Pump can be used between 0 and 40 degrees centigrade.
