BEA Eagle - SETTINGS; REMOTE CONTROL; ACCESS CODE; PUSH BUTTONS

auto
< 10 ft
open
> 10 ft
closed
6
XXS
0.5 s
XS
1.5 s
low
bi
A
S
3 s
normal
uni
P
>
5 s
high
uni
MTF
>
7 s
>
uni
AWAY
>
9 s
>
MTF &
AWAY
>
10 s
>
L
15 s
L
XL
20 s
XL
XXL
reset
30 s
highest
+> 2 sec
75.5601.04 EAGLE 20240412 Page 5 of 8
SETTINGS
MOUNTING HEIGHT
DOOR CONTROL
bi = two-way detection
uni = one-way detection towards sensor
uni MTF = one-way detection with motion tracking feature
uni AWAY = one-way detection away from sensor
A = active output (NO-contact); relay energizes upon detection
P = passive output (NC-contact); relay de-energizes upon detection
ACCESS CODE
Program the sensor for the desired application, using the remote control or push button options.
When mounting at the maximum height, the sensor manufacturer recommends the following:
Immunity = low
Zone Size = XXL
ZONE SIZE
FACTORY RESET
IMMUNITY FILTER
DETECTION MODE
OUTPUT
CONFIGURATION
HOLD-OPEN TIME
FACTORY RESET
ZONE SIZE
REMOTE CONTROL
PUSH BUTTONS
Access codes (1 to 4 digits) are recommended to set sensors installed close to each other.
SAVING ACCESS CODE:
DELETE ACCESS CODE:
Once you have saved an access code, you always need to enter this code to unlock the sensor.
If you forget the access code, cycle the power. For the first minute, you can access the sensor without an
access code.
FACTORY VALUES
open = the sensor detects constantly. The LED is ON.
closed = the sensor is in standby and does not detect. The LED is OFF.
