Beckhoff CX1020 Series User Manual

Product overview
30 Embedded PC
Technical data CX10x0-N010 CX10x0-N020
CX10x0-N030
CX10x0-N040
CX10x0-N031
CX10x0-N041
Interfaces 1 x DVI +
2 x USB 2.0
max. 100 mA
per port
Line IN,
MIC IN,
Line OUT
1 x COM1+2,
RS232
1 x COM3+4,
RS232
1 x COM1+2,
RS422/RS485
1 x COM3+4,RS422/RS485
Connection type DVI-I 29-pin
socket + 2 USB
Ports type A
3,5 mm socket
for jack plug
2 x D-Sub plug
9-pin
2 x D-Sub plug 9-pin
Properties DVI-I interface
also carries out
VGA signals
(DVI-A)
built-in PC-
Beeper
Line OUT output,
max. 200 mW,
suitable for
earphones
max. baud rate
115 kbaud,
can not be used
simultaneously with
N031/N041
max. baud rate 115 kbaud,
can not be used
simultaneously with
N030/N040
Power supply via system bus (Through CX1100-000x power supply module)
Dimensions 19 mm x 100 mm x 51 mm
Operating temperature 0 °C ... +55 °C
Storage temperature -25 °C ... +85 °C
Relative humidity 95% no condensations
Vibration/Shock resistance conforms to EN 60068-2-6 / EN 60068-2-27/29
EMC resistance burst / ESD conforms to EN 61000-6-2/EN 61000-6-4
Protection class IP 20
weight app. 80 g
Technical data CX10x0-N060
Interfaces 1 x Ethernet 10/100 Mbit
Connection type 1 x RJ45
Properties network connection for enhanced
PC104 Bus
Power supply via system bus (Through CX1100-000x power supply module)
Dimensions 19 mm x 100 mm x 51 mm
Operating temperature 0 °C ... +55 °C
Storage temperature -25 °C ... +85 °C
Relative humidity 95% no condensations
Vibration/Shock resistance conforms to EN 60068-2-6 / EN 60068-2-27/29
EMC resistance burst / ESD conforms to EN 61000-6-2/EN 61000-6-4
Protection class IP 20
weight app. 80 g
